Development path of TSD Smart Modules
May 08 , 2024

Come with TSD to explore the development of smart display modules



Gen1 - TSDPro Series:

This is the first generation of TSD Smart Modules, its coming out with a series port, UART interface, using Levetop controller, which support the visual UI operation, simple and fast development on HMI.



Gen2 - Initial version with knob display modules (EOL):

The second generation of TSD Smart Modules featured an initial version with a knob display, including 1.08 inch, 1.3 inch and 2.1 inch. However, this version has been EOL and TSD have development a new version on it.



Gen3 - Knob series and smart display with STM32 controller:

The third generation of TSD Smart Modules is powered by an STM32 microcontroller. The STM32 microcontroller is a popular series of microcontrollers developed by STMicroelectronics. We have development the new knob solution basing on it, as well as developed 2.4 inch, 3.99 inch and 7 inch smart display which using for air purifier solutions, etc.



Gen4 - STM32H7R controller series (latest version):

The fourth generation of TSD Smart Modules utilizes the STM32H7R series controller as the main controller, designing for 4.3 inch, 5 inch, 7 inch, 10.1 inch LCD display series. The STM32H7R is an advanced microcontroller based on the ARM Cortex-M7 architecture. This series appears to be the latest version, which would be come into the market in the coming 1~2 months.





TSD Smart Modules offer the following features and capabilities:



Ø Multimodal human-computer interaction

Ø Powerful 2.5D NeoChrom GPU - smart DMA architecture memory/GPU, High refresh rate and smooth full screen animation effects

Ø Integrated with TUYA WiFi module, using SDIO communication, achieving high-speed remote OTA function

Ø Rich peripheral interfaces:UART, RS485, RS232, Type-C and with a 40pin GPIO expansion interface

Ø Integrated buzzer, support chord sounds

Ø High reliability and performance, widely applicable to industries such as home appliances, industry, and new energy applications.



TSD smart modules can be integrated into different products or systems within these industries to enhance their functionality and user experience, providing reliable performance and excellent user experience to meet various application needs. It's always recommended to contact Team Source Display for precise specifications or any further inquiries. As a LCD display manufacturer and solutions provider for 20 years in the display market, were always happy to help and support our customers from all over the world.
