Home /Standard TFT LCD display (TN) /

10.1 inch TFT

 /1024x600 resolution 10.1 inch touch screen TFT LCD display with RGB interface

1024x600 resolution 10.1 inch touch screen TFT LCD display with RGB interface


10.1 inch LCD with CTP
10.1 inch LCD with CTP 10.1 inch LCD with CTP

1024x600 resolution 10.1 inch touch screen TFT LCD display with RGB interface


Inquiry now

1024x600 resolution 10.1 inch touch screen TFT LCD display with RGB interface



Specification
LCD type 10.1" tft lcd display Module
Display type 10.1 inch TFT, 16.7M color, normally white
Driver element color active matrix thin film transistor
Backlight white LED
Outline Dimension(mm) 235*143*6.65
Active Area.(mm) 222.72*125.28
Resolution(dots) 1024xRGBx600
Viewing Direction 12H
Operating temperature(°C) -20-70
Storage temperature(°C) -30-80
Backlight LEDs
  24 white LEDs
Color depth
 16.7M
Luminance(cd/m2) 425(typ.)
TP/Lens with CTP (GT928)
Application Notebook, advertisement display, etc.
IC HX8282+HX8689
Interface  RGB
Module lifetime(Hours) 50,000-100,000

Get A Quote
If you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.
