Description:
TST32QV08B is 3.2 inch 240*320 resolution LCD display with MCU interface, standard brightness is 320 cd/m2, which is suitable for indoor and outdoor application. For this 3.2 inch lcd module, driver IC is ILI934AV , viewing direction is All o’clock , color depth is 16.7M, this lcd module is without standard Capacitive touch panel, customized design are also welcome.
Drawing:
Specification
|
General Specification |
||
|
Part No. |
TST32QV08B |
|
|
Display Size(Diagonal) |
3.2 inch |
|
|
LCD type |
TFT,Transflective,Normally white |
|
|
Resolution |
240*320 |
|
|
View Direction |
ALL o’clock |
|
|
Module Outline |
55*77*2.57 |
|
|
Active Area |
48.6*64.8 |
|
|
Viewing Area |
ALL o’clock |
|
|
Backlight |
LED |
|
|
Driver IC |
ILI9341V |
|
|
Interface |
MCU |
|
|
Weight(g) |
TBD |
|
|
Power Consumption(w) |
Panel |
TBD(Typ.) |
|
B/L system |
TBD(Typ.) |
|
|
Operating Temperature |
-20～70 |
|
|
Storage Temperature |
-30～80 |
|
Applications:
1. Office Electronic Equipment: money counting machine, office phone set, copying mechine.
2. Household Appliances: refrigerator, air conditioner, induction cooker, microwave ovens.
3. Instruments: clinical thermometer, wire tester, digital watches, electronic weight scale.
4. Medical Devices: sphygmomanometer, ECG machine
5. Sports Equipment: Running machine.
6. Industrial Control Equipment: remote control, punched-card machine.
7. Information Terminal Display: POS, PDA, Handheld devices.
